EMAC can provide software Board Support Packages (BSPs) for our Single Board Computers (SBCs) using your choice of compatible Operating Systems. Integration of the single board computer into an enclosure, adding memory, CPU, Wireless (WiFi, Bluetooth or Mesh), storage solution & loading an OS, in most cases is free with the purchase of the Single Board Computer and related components. Addionally EMAC has LCD- Panel Kits with Touchscreen options, allowing our Single Board Computer Solutions to utilize an LCD for video output and a touchscreen replacement of a mouse for input.

The LCD Panel Kit with the Touchscreen option in conjunction with the Flash Disk, makes for a Solid State Embedded computer system that is ideal for rugged, wide temperature, and low downtime environments. If you cannot find exactly what you need from our large Off-The-Shelf selection, EMAC can potentially customize any hardware or software component, and additionly offer driver development and software application programming, providing you with the perfect fit for their SBC application needs. EMAC can provide Enclosures, I/O Modules, Peripherals, Memory, and Operating Systems for most of our x86 and ARM SBCs. EMAC supports and can install the the following Operating Systems on Hard Drive or Flash Disk: Embedded Linux, Xenomi Development Framework, ROMDOS, Windows CE, and Windows Embedded Standard, Windows 10 IoT or Windows 10 IoT Core.

[woof_text_filter]

Search & Shop

[wcas-search-form]

  • The EPIC-BT07 caters to the needs of the market through six COM ports, an interface still popular among most industrial users.
    • Onboard Intel® Atom™ E3845 or Celeron® J1900/N2807 Processor
    • Up to 8GB DDR3L SODIMM
    • 6x serial ports
    • 1x USB 3.0, 5x USB 2.0 Ports
    • 2x Gigabit Ethernet
    • VGA, HDMI & LVDS

  • MIO-5271 is designed using MI/O Extension form factor (compact series, 146 x 102 mm) and powered by the latest generation of Intel Core U series processors which have low power features but also high performance computing and multimedia capabilities.
    • Haswell 4th Gen Intel® Core™ U-series (i5/Celeron®)
    • 1 x DDR3L-1600/1333 SO-DIMM support up to 8 GB
    • DirectX11.1, OpenGL4.0, OpenCL1.2, 3 independent display: VGA + LVDS + HDMI/Displayport*
    • Optimized thermal design with fanless solution for wide temperature
    • Flexible design using integrated multiple I/O: MIOe
    • Rich I/O interface with: 2x GbE LAN, HD Audio, 4x COM, 2x SATA, SMBus/I2C, 8x GPIO, Half-size Mini PCIe, Full-size Mini PCIe w/ mSATA & 2x USB 3.0

  • MIO-5251 is designed using MI/O Extension form factor (compact series, 146 x 102 mm) and powered by the latest generation of Intel Celeron J1900 and Atom E3825 processors which have low power features but also good performance computing, especially for multimedia capabilities compared to earlier generations.
    • Intel® Celeron J1900 & Atom™ E3825/E3845
    • SODIMM up to 8GB DDR3L
    • multi-display: VGA, LVDS & HDMI/DP*
    • Flexible design using integrated multiple I/O: MIOe to approach vertical
    • applications & keep domain knowhow
    • 2x GbE, 4x COM, SATA, USB3.0, SMBus/I2C, GPIO
    • full-size Mini PCIe w/ SIM holder, full-size mSATA or SD card

  • MIO-2263 is a MI/O-Ultra SBC (Single Board Computer) with Embedded Intel Atom SoC J1900 2.0 GHz and E3825 1.33 GHz Processor.
    • Embedded Intel® Atom™ E3825 Dual Core or Celeron J1900 Quad Core
    • Up to 8GB DDR3 SODIMM
    • 1x RS-232 & 1x RS-232/422/485/
    • 4x USB 2.0 Ports & 1x USB 3.0 Port
    • Gigabit Ethernet
    • VGA, HDMI & LVDS

  • The iPac HCS12 is a powerful Single Board Computer (SBC) based on the Freescale 68HCS12 processor. Although being extremely powerful with ample I/O for demanding applications, this board consumes minimal power, is low cost, and has a small footprint. Pricing based on IPAC HCS12 (MOQ 25)
    • Freescale 68HCS12 16 Bit Processor 50 MHz
    • 256K Flash programmable, 4K byte EEPROM, 12K of RAM, 96 bytes of battery backed RAM.
    • 16 General Purpose HCS12 Digital I/O lines
    • 1 RS232 Port and 1 RS232/422/485 port.

  • EMAC, Inc.; a leader in compact low power single board computer design and manufacturing has created the iPAC-9X25. Made in the USA this industrial strength embedded single board computer is based on Atmel AT91SAM9X25 Processor. Pricing based on 400 MHz, 128MB DDR2, 4GB of eMMC and 16MB Serial Data Flash
    • Atmel AT91SAM9x25 400 Mhz Processor with 133 Mhz System Bus
    • 16MB serial Flash, 128MB DDR2 RAM and 4GB eMMC
    • 20 General Purpose SAM9x25 Digital I/O lines, 16 SPI I/O Expander Based Digital I/O lines, and 8 High Drive Digital Outputs
    • Up to 7 channels of 10 bit A/D, Up to 4, 16-bit PWMs
    • -40°C to +85°C
    • Optional: Wi-Fi and Bluetooth

  • EMAC has created the iPac-9302, an inexpensive, feature packed embedded Single Board Computer (SBC) based on the Cirrus EP9302 processor. This ARM9 based board has features, similar to our other Microcontrollers, A/D, PWM, Digital I/O, Serial, USB, and Ethernet. Pricing based on IPAC 9302 IPAC 9302 W/ 16MB FLASH & RAM
    • Cirrus Logic EP9302 ARM9 200 Mhz Processor with 100 Mhz System Bus
    • 1 RS232 Serial Port with handshake
    • 1 RS232/422/485 configurable Serial Port
    • 16 MB of External Flash

  • The Mitipy Industrial IoT microcontroller was created to simplify connecting devices and machines to the multitude of systems you find in the Industrial environment EMAC Inc. has created an easy to use, cost effective industrial board that can be implemented anywhere from the factory floor to an offsite remote location.
    • STMicroelectronics RM Cortex-M4 168 MHz Low Power
    • 192 KB of SRAM, Up to 1M of Flash
    • 1x 100 BaseT Ethernet (Standard), POE (Optional)
    • 16x GPIO, 4x Serial Ports, 2x USB, SDIO, A/D, SPI, I2C & CAN
    • Optional Wifi, Bluetooth, Cell Modem SKT w/GPS.
    • M2.COM IoT connector
    • MicroPython, FreeRTOS or EMAC OE Linux
  • The HSB-800I is an economic half-size ISA Single Board Computer (SBC) based on the AMD LX800 processor with a LVDS/TTL VGA controller and an optional 1000 Base-T Ethernet interface. The HSB-800I achieves outstanding performance and low power consumption.
    • Fanless LX800 500 MHz Processor
    • Up to 1000 Mbps On-board Ethernet
    • ISA & PC/104 Expansion
    • Supports 128MB On-Board DDR400 Memory

  • GENE-BT05 adopts Intel Celeron N2930/N2807 Processor. The system memory is deployed with 204-pin SODIMM DDR3L 1066/1333 up to 8 GB.
    • Intel® Atom™ and Celeron® Processor
    • 2x Gigabit Ethernet
    • Up to 8GB of DDR3L memory
    • VGA, LVDS and HDMI
    • Onboard 4/5/8-wire Resistive Touch Screen Controller (Optional)

  • The EMB-BSW1 is a new industrial motherboard with the N3000 series CPU. As its name suggests, the EMB-BSW1 utilizes the latest iteration of Intel’s SoC products that was geared specifically towards mobile devices.
    • Intel® N3710/N3060 Processor
    • Up to 8 GB DDR3L 1333/1600 MHz 2x SODIMM
    • Three Independent Display: 2x HDMI & LVDS
    • SATA 6.0 Gb/s x 3
    • 4x USB 3.0, 2x USB 2.0
    • Half-size Mini-Card (PCIe + USB),
    • Full-size Mini-Card (mSATA)
    • 12-24V DC
    • Low Profile

  • MIO-5272 is designed using MI/O Extension form factor (compact series, 146 x 102 mm) and powered by 6th "SkyLake" generation of Intel Core U series processors which have low power features but also high performance computing and multimedia capabilities.
    • 6th Gen Intel® Core™ U-series "SkyLake" (i7/i5/i3/Celeron®*)
    • 2 x DDR3L-1600/1333 SODIMM support up to 16 GB
    • DirectX 11.3, OpenGL 4.4, OpenCL 2.1, 3 independent displays: VGA + LVDS + HDMI
    • Flexible design using integrated multiple I/Os: MIOe to approach vertical applications & keep domain knowhow.
    • 2xGbE support, HD Audio, Rich I/O interface with 2x COM, 2x SATA, SMBus/I2C, GPIO, 2x Full-size Mini PCIe (one w/ mSATA), 4x USB 2.0, 2x USB 3.0 and TPM2.0*
    • Supports Intel AMT11.0, WISE-PaaS/RMM and Embedded Software APIs

  • PCI-7032 is an Intel based PICMG 1.0 half-size PCI interface single board computer. PCI-7032G2, with Intel Celeron J1900, offers a dual GbE LAN, high computing solution; PCI-7032VG, adopting Intel Atom N2930, provides a single GbE LAN and fanless computing core with high reliability that resists heat, dust, vibration and shock in any application environment.
    • Intel® Celeron J1900 Or N2930 Ultra Low Power
    • Up to 8GB DDR3L SODIMM
    • Up to 4x RS-232/422/485
    • Up to1x USB 3.0, 6x USB 2.0 Ports
    • VGA, LVDS & DVI
    • Dual Gigabit Ethernet

  • PCM-3365 is PC/104-Plus form factor (96 x 90 mm) and powered by the latest generation of Intel Celeron N2930 and Atom E3825/E3845 processors which have low power features but also good computing performance, especially for multimedia capabilities compared to earlier generations.
    • Intel® Atom™ E3825/E3845 or Celeron® N2930
    • Up to 8GB DDR3L SODIMM
    • 2x RS-232 & 1x RS-232/422/485
    • 6x USB 2.0 Ports
    • 1x Gigabit Ethernet
    • 1x SATA & 1x mSATA
    • VGA, LVDS &HDMI/DVI

  • The PCM-5315 is based on the AMD Geode LX800/900 500/600 Mhz CPU and is designed to provide the ideal combination of low power, great performance, widely expanded interfaces and small size for applications that require a small form factor and lower-scale processor support. Pricing based on Geode LX800 500 MHZ, SODIMM RAM, Compact flash, 2x COM, 4x USB2, 2x LAN, VGA, TTL, LVDS
    • Fanless AMD Geode LX800/900 500/600 Mhz Processor
    • Up to 1GB SDRAM Memory
    • 1920x1440@24bpp Resolution w/ shared memory up to 254MB
    • MiniPCI & PC/104 Expansion

  • The PCM-9375 is based on the AMD LX800 500Mhz CPU and is designed to provide the ideal combination of low power, great performance, widely expanded interfaces and small size for applications that require a small form factor and lower-scale processor support.
    • AMD Low Power LX800 500MHz Fanless Processor
    • Up to 1GB DDR SDRAM
    • Up to 1920x1440 @ 32bb Video
    • 4x Serial Ports, 4x USB 2.0, Dual 100 Base-T Ethernet
    • PC/104 Expansion
  • The PCM-9376 is an AMD G-Series Single Core T16R processor + A55E, DDR3 on-board 1GB SDRAM (optional) or SODIMM up to 4GB.
    • AMD G-Series Single Core T16R processor + A55E, DDR3 SODIMM up to 4GB
    • DirectX11 supported. 48-bit LVDS, VGA, 18-bit TTL (optional)
    • Intel dual GbE, 4 COM, 2 SATA, mSATA
    • Expansion: PC/104, mini PCIe, LPC connector for additional COM ports
    • Variations Include: PCM-9376E-M, PCM-9376E-M1G, PCM-9376E-S, PCM-9376EZ-M, PCM-9376EZ2-M, PCM-9376F-M

  • The PCM-9563's design is based on the EBX form factor and provides expansion support via PCI-104, a PCI slot, M.2, mSATA and a Mini PCI Express slot.
    • Embedded Intel Celeron N3350
    • Up to 8GB DDR3L SODIMM
    • DirectX11, OpenGL3.2, OpenCL1.2, multi-display: VGA+LVDS/eDP+ HDMI*/ DP*
    • Supports up to 3 Intel i210 GbE LAN ports
    • 6x COM, 1 Mini PCIe, 1 M.2 E-key, 1 mSATA, PCI-104 and 1 PCI Slot
    • High transfer speed COM port design (Transfer rate up to 1 Mbit/s)
    • Design complies with CE/FCC
