VOX-084

Setting up a Panel PC can be a Puzzling experience. However, when purchased with an Operating System and Compact Flash, the VOX-084 Compact Panel PC comes ready to run. Everything works out of the box, allowing you to concentrate on your application, rather than building and configuring device drivers. Just Write-It and Run-It.

  • 8.4″ Modular Open-Frame Design
  • DM&P Vortex86DX2 800MHz or Vortex86DX3 1GHz processor
  • Up to 1GB on-board DDR2 SDRAM
  • 4x Serial Ports, 3x USB 2.0 Ports
  • 4-Wire Resistive Touch Screen

Product Variations

Name VOX-084-0200 VOX-084-0300
Price Call Call
ATTRIBUTES
Screen size 8.4″ 8.4″
CPU Vortex86DX2 Vortex86DX2
Number of Cores 1 1
Speed 933MHz 933MHz
RAM 512MB 512MB
Primary flash SATA SATA
Serial ports 4xCOM 4xCOM
USB 2.0 3x USB2 3x USB2
Ethernet LAN LAN
Audio Audio Audio
Secondary video VGA VGA
Voltage 5 & 12 V 5 & 12 V
Temperature 0° to 50°C 0° to 50°C

Additional information

PPC STYLE

PPC SCREEN SIZE

PPC TOUCHSCREEN TYPE

PPC LCD DISPLAY TYPE

PPC LCD RESOLUTION

PPC ASPECT RATIO

LCD LUMINANCE

PROCESSOR TYPE

DM&P Vortex86DX2 or Vortex86DX3

PROCESSOR CLOCK SPEED

800 MHz

PROCESSOR CORES

Single

RAM

Up to 2GB DDR3 onboard

STORAGE

Onboard 4MB Flash Disk (Optional) EmbedDisk Module / Compact Flash Type I/II (Optional)

VIDEO

VGA, TFT or LVDS

AUDIO FILTER

, ,

AUDIO

ALC 262 (HD Audio) with Mic-In/Line-In/Line-Out

ETHERNET

1x 10/100 Base-T Ethernet with on-Board RJ-45 connector 2x 10/100/1000 LAN headers

POE

Wireless

N/A

Bluetooth

N/A

SERIAL PORTS

4x RS232/422/485

USB 3.0

N/A

USB 2.0

3x USB 2.0

CAN

N/A

I2C

N/A

SPI

N/A

GPIO

16x GPIO Lines

Timer/Counters/PWM

ANALOG IO

N/A

BUS EXPANSION

N/A

Mini-PCIe

PCI

MINI PCI

SIZE

9 x 5.9 x 1.1 inches (W x H x D)

LOW OPERATING TEMPERATURE

0° C

HIGH OPERATING TEMPERATURE

50 C

UPPER OPERATING HUMIDITY

N/A

VOLTAGE

5 to 12V

Description

Setting up a Panel PC can be a Puzzling experience. However, when purchased with an Operating System and Compact Flash, the VOX-084 Compact Panel PC comes ready to run. Just apply power and watch either the Linux X Windows or the Windows XP/CE User Interface appear on the vivid color LCD. Interact with the VOX-084 using the responsive integrated touchscreen. Everything works out of the box, allowing you to concentrate on your application, rather than building and configuring device drivers. Just Write-It and Run-It. The VOX-084 features:

  • Fanless DM&P Vortex86DX2 800MHz or Vortex86DX3 1GHz processor.
  • Based on the VDX3-6726 or VDX2-6526
  • Inexpensive Open-Frame Design
  • 10/100BaseT Ethernet
  • 4x Serial ports with handshake
  • 3x USB 2.0 Host ports (one USB taken by Touchscreen)
  • Up to 1 GB of On-Board SDRAM
  • Audio with Mic-In/Line-In/Line-Out
  • 8″ Graphic LCD Interface
  • SVGA (800 x 600) LCD Resolution
  • Touchscreen Interface
  • 47 Watt Power Supply Included

___________________________________________________________________________

EMAC is a global leader in industrial automation and HMI Panel PCs.  We provide Panel PCs for embedded automation computers, automation controllers, remote i/o modules, and custom data acquisition solutions.

EMAC’s Panel PCs are available ready to run with the Operating System installed on flash disk or hard drive. Apply power and watch either the Windows or Linux User Interface appear on the vivid color LCD. Interact with the PPC using the responsive integrated touchscreen. Everything works out of the box, allowing you to concentrate on your application, rather than building and configuring device drivers. Just Write-It and Run-It.

Contact the EMAC Panel PC Sales Department for details on Sunlight Readable Panel PC, IP65 Panel PC, IP67 Panel PC, Wide Voltage Panel PC, and/or Low Power Consumption Panel PC specifications.

Interested in custom engineering? Learn more.

Search our video library.

Downloads

MANUALS
vox-084.pdf
VMXP-6427_UM.pdf

DATA SHEETS
OpenFrame_LCDSET_DS.pdf
6427_datasheet.pdf

Peripheral Options

PRODUCT # DESCRIPTION PRICE
STORAGE MEDIA
PER-FLS-00247-R 8GB SATA DOM MLC Standard Temperature (0 to 60°C) Call
OPERATING SYSTEMS
SL05x-XON-xx EMAC OE Linux 5.x for x86 (Free installation at time of purchase of SBC & media) Free
SX300-000-0000D Windows Embedded Standard 2009 (WES09) & License (Base configured installation included with License, Flash and SBC purchase; SOLD ONLY WITH HARD DRIVE OR FLASH DRIVE MEDIA) Call
S7000-NOL-00020 Windows Embedded Standard 7 (WES7) & License SOLD ONLY WITH HARD DRIVE OR FLASH DRIVE MEDIA Call
