ROM-5620 – SMARC Module

The ROM-5620 SMARC 2.0/2.1 Computer-on-Module is powered by NXP i.MX 8X SoC which includes two to four Arm Cortex-A35 cores for mid-range automotive and industrial market segments, one Cortex-M4F core for real-time processing, and one Tensilica Hi-Fi 4 DSP for efficient audio and voice codec execution. It also escalates its graphic performance by Vivante GC7000 Lite, 4K H.265 capable decoder, and dual 1080P60 display controller.

  • NXP i.MX 8 XPlus processor with dual or quad ARM Cortex A35 cores
  • 1 x Arm Cortex-M4F core
  • Tensilica® HiFi 4 DSP
  • Onboard 2GB LPDDR4 memory and eMMC 16GB
  • 2x LVDS, 2x 4-Lane MIPI DSI
  • Support OpenGL ES 3.1/3.0/2.0/1.1 and Open CL 1.2, and Vulkan hardware accelerators
  • Supports 4K hardware decode engine
  • Supports Linux and Android BSP

Product Variations

Name ROM-5620WU-OE
Price Call
ATTRIBUTES
ATTRIBUTES
Format Custom
CPU NXP i.MX 8 Xplus
Number of Cores Quad
Speed 1.2GHz
Memory 2GB LPDDR4
Storage Flash 16GB eMMC
Storage SDIO
Serial 4x COM
Other Serial SPI, I2C, CAN
USB3.0 1x USB 2.0
USB2.0 2x USB 2.0
USB Device/OTG 1x USB 2.0 OTG
Ethernet PHY 10/100/1000 Ethernet
Expansion 1x PCIe 3.0
GPIO 12x GPIO
Audio 2 x I2S
Video 2x 24-bit single channel LVDS 1080p or 2x 4-LANE MIPI DSI
Operating temperature -40 ~ 85 °C

Additional information

FORM FACTOR

SMARC

PROCESSOR TYPE

NXP i.MX 8 XPlus processor with dual or quad ARM Cortex A35 cores

PROCESSOR CORES

Dual, Quad (or more)

PROCESSOR CLOCK SPEED

1.2 GHz

RAM

2GB LPDDR4 onboard

FILTER EXPANSION

PRIMARY FLASH

16GB eMMC NAND Flash

SECONDARY FLASH

8MB QSPI NOR Flash for board information

MEMORY MISC.

NA

DISK INTERFACE

NA

BIOS / BOOTLOADER

available on request

AUDIO

2x I2S Audio

VIDEO OUT

2x 24-bit single channel LVDS 1080p or 2x 4-LANE MIPI DSI

ETHERNET

2x 1000BASE-T Ethernet NXP i.MX8X integrated RGMII

SERIAL PORTS

3x UART (1x 4-wire UART, 2x 2-wire UART)

USB

1x USB 3.0, 1x USB 2.0 OTG, 1x USB 2.0 Host

CAN

2x CAN 2.0 A/B

I2C

4x I2C with interrupt

SPI

2 SPI

GPIO

12x GPIO

SDIO

1x SDIO

TIMERS/ COUNTERS/ PWM

see datasheet

TOUCH

see datasheet

A D CHANNELS

NA

A/D RESOLUTION

NA

BUS EXPANSION

1x PCIe 3.0

OPERATING SYSTEMS

EMAC OE Linux, Android

SIZE

3.23" × 1.97" (82mm × 50mm)

VOLTAGE

4.75~5.25V

POWER MISC.

Power Consumption: 4.45W (Max)

TYPICAL CURRENT

see datasheet

MAX BOOT CURRENT

see datasheet

CONSTANT BUSY LOOP CURRENT

see datasheet

IDLE CURRENT

see datasheet

LOW OPERATING TEMPERATURE

0

HIGH OPERATING TEMPERATURE

60

UPPER OPERATING HUMIDITY

95% relative humidity, non-condensing

ENVIRONMENTAL MISC.

'-40°C ~ +85°C (Optional) Heat-spreader / heat-sink are required for proper heat dissipation. Request details

FILTER AUDIO

I2S

FILTER PROCESSOR FAMILY

Description

The ROM-5620 SMARC 2.0/2.1 Computer-on-Module is powered by NXP i.MX 8X SoC which includes two to four Arm Cortex-A35 cores for mid-range automotive and industrial market segments, one Cortex-M4F core for real-time processing, and one Tensilica Hi-Fi 4 DSP for efficient audio and voice codec execution. It also escalates its graphic performance by Vivante GC7000 Lite, 4K H.265 capable decoder, and dual 1080P60 display controller.
ROM-5620 is paired with ROM-DB5901 Evaluation Carrier Board for faster end product peripheral integration and time-to-market. The reference schematics and layout checklists documentations for carrier board development will be provided along with the open-sourced Linux BSP, test utilities, hardware design utilities and reference drivers.

  • NXP i.MX 8 XPlus processor with dual or quad ARM Cortex A35 cores
  • 1 x Arm Cortex-M4F core
  • Tensilica® HiFi 4 DSP
  • Onboard 2GB LPDDR4 memory and eMMC 16GB
  • 2x LVDS, 2x 4-Lane MIPI DSI
  • Support OpenGL ES 3.1/3.0/2.0/1.1 and Open CL 1.2, and Vulkan hardware accelerators
  • Supports 4K hardware decode engine
  • Supports Linux and Android BSP

___________________________________________________________________________

EMAC is a global leader in system on module and carrier board embedded systems.  The System on Module (SoM) is an ideal alternative to custom engineering. With the SoM approach you get the best of aspects of both buying an Off-The-Shelf Embedded Single Board Computer (SBC) and a Custom Engineered solution. With Off-The-Shelf embedded components such as a generic carrier board and SOM module, it is possible to start development on your software applications before the custom carrier board is complete; thus offering a reduced time to market for your system. A System on Module (SoM) is comprised of a small processor module with CPU bus accessibility and standard I/O functionality. The SoM module does not have any connectorization and is designed to be plugged into a Carrier Board.

Interested in custom engineering? Learn more.

Search our video library.

Downloads

MANUALS
ROM-5620 manual.pdf

DATA SHEETS
ROM-5620_DS.pdf
